Yamaha

Yamaha HA-L7A Headphone Amplifier [ Vinyl ]

Yamaha HA-L7A Headphone Amplifier [ Vinyl ]

£824.99 GBP
£824.99 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

The Yamaha HA-L7A is a headphone amplifier that allows you to dive into your favorite content, by fusing superior Hi-Fi audio technologies with sound field advancements from AV receivers.

  • Yamaha's unique Floating and Balanced Power Amplifier technology optimized for headphone listening
  • Adopting ESS Technology's ES9038PRO to realize superior sonic quality
  • 2 toroidal transformers for remarkable spacious sound
  • SOUND FIELD mode for more immersive experience in any content
  • Pure Direct mode to fully enjoy the subtest nuances in the music
  • Elegant design yet high rigid construction
  • 5 solid metal feet for exceptional stability and suppress any vibration
  • OLED display with brilliant viewability
HA-L7A
Frequency response (HP OUT) 4 Hz - 80 KHz, -3 dB
Headphone Output φ6.3㎜ 1,000 mW + 1,000 mW (1 kHz, 0.01 %THD, 32 Ω)
φ4.4㎜ 1,000 mW + 1,000 mW (1 kHz, 0.01 %THD, 32 Ω)
XLR4 1,000 mW + 1,000 mW (1 kHz, 0.01 %THD, 32 Ω)
Total Harmonic Distortion(THD) ≦ 0.003 % (Digital IN 1 kHz, 300 mW, 32 Ω)
Signal to Noise Ratio (SNR) > 120 dB
Input RCA Yes
Optical Yes (PCM: 32/44.1/48/88.2/96 kHz, 16/24 bit)
Coaxial Yes (PCM: 32/44.1/48/88.2/96/176.4/192 kHz, 16/24 bit)
USB Type-B Yes (PCM: 44.1/48/88.2/96/176.4/192/352.8/384 kHz, 16/24/32 bit, DSD: 2.8 MHz/5.6 MHz/11.2 MHz: ASIO Native, DoP)
PRE/LINE Out XLR3 Yes
RCA Yes
Recommended Headphones impedance 32 ～ 600 Ω
SOUND FIELD mode Yes (CINEMA/DRAMA/MUSIC VIDEO/CONCERT HALL/OUTDOOR LIVE/BGM + STRAIGHT)
Pure Direct Yes
Power Consumption 19 W
Standby Power Consumption 0.2 W
Dimensions (W x H x D) 333 x 133 x 189 mm; 13 1/8" x 5 1/4" x 7 1/2" (w/ Trans, Leg, knob, terminal)
Weight 5.3 kg, 11.7 lbs
